RPT-001 relay protection tester, with energy meter calibration function (hardware ready to activate). The equipment strictly complies with IEC 62271-203 and other standards, with precise voltage and current output and advanced frequency phase control, and rich input and output interfaces. It provides reliable guarantee for relay performance testing, and also provides 3 years of free repair, lifelong maintenance and free software upgrade services.

Product Introduction

RPT-001 relay protection tester is a professional relay performance test equipment, designed for performance testing of relays in power systems. The equipment not only integrates advanced technology and provides comprehensive test functions, from basic electrical parameter output to complex relay function testing, to help the power industry ensure reliable operation of relays, but also strictly complies with international standards to ensure product quality and performance.

Product Features

• Multi-channel high-precision output: 10 channels (6×35A and 4×310V) independent output, can simultaneously control amplitude, phase angle and frequency values, can inject DC, AC sine waves and up to 60 harmonics. High accuracy of voltage and current output, frequency accuracy of ±0.5ppm.
• Rich and diverse functions: with variable battery simulator (DC 0 - 350V, maximum 140W), transient playback up to 3KHz, full-featured KRT software test module, graphic test module and template, etc.
• Reliable synchronization and connection: GPS synchronization mode (SMA type antenna connector) ensures test synchronization; RJ45 Ethernet interface is convenient for connection to PC.
• Safe and stable: with anti-clipping detection, wrong wiring connection alarm, self-protection, overload and overheating protection functions; adapt to a wide range of power input and working environment.
• Convenient operation and maintenance: manual mode can quickly test relays; automatically create test reports; provide 3 years free repair guarantee, lifetime maintenance and free software upgrades.
• Standard compliance: In accordance with IEC 62271-203, the test function of the device can ensure that the annual leakage rate meets the standard requirements (≤0.5%) for the SF6 gas tightness detection of high-voltage switchgear, thus ensuring the detection accuracy and compliance of related equipment.

International reference standards

• IEC 62271-203 Specification for SF6 gas tightness test of high-voltage switchgear, requiring annual leakage rate ≤ 0.5%.
• MT/T 845-1999 Technical specification for SF6 tracer gas detection in coal mine tunnels, applicable to leakage monitoring in closed environments.
• ISO 9001:2015 quality management system certification ensures standardization of product production and services.

Test objects

All kinds of power system relays, such as overcurrent relays, overvoltage relays, undervoltage relays, differential relays, zero-sequence relays, etc., as well as mechanical meters and electronic meters (related to the calibration function of electric energy meters). When it comes to the SF6 gas sealing detection of high-voltage switchgear, the relevant equipment can be tested.

Test items

• Relay action characteristic test: Detect the relay's action time, return time, action value, return value and other parameters to evaluate the accuracy and reliability of its action.
• Electrical parameter test: Including the output and measurement of electrical parameters such as voltage, current, frequency, and phase angle to verify the performance of the relay under different electrical conditions.
• Harmonic test: Inject up to 60 harmonics to test the operation of the relay in a harmonic environment.
• Synchronous test: Use the GPS synchronization function to test the consistency of the relay's action under synchronous conditions.
• Fault simulation test: Through functions such as the switch-on fault test (SOTF), simulate power system faults and detect the protection function of the relay.
• SF6 gas tightness test: For high-voltage switchgear, according to IEC 62271-203 standard, the annual leakage rate of SF6 gas and other tightness parameters are tested.
